PS Audio Stellar Gold DAC

PS Audio Stellar Gold DAC

Regular price $7,495.00 AUD
Regular price Sale price $7,495.00 AUD
Sale Sold out
Tax included. Shipping calculated at checkout.
Colour

Stellar Gold DAC

Once in a great while, an exciting new product design direction comes along that really sets a new standard for performance within a price range. Such is the all new StellarGold DAC, a product that will raise the bar for any digital to analog converter at anywhere near the price.

What makes the new StellarGold DAC unique is its use of multiple parallel DACs. Each channel of the StellarGold is built by paralleling 4 high resolution digital to analog converters, then feeding the combined output of these DACs into an all new discrete class A analog output stage. The results are nothing short of stunning. The use of multiple high-precision DACs to form one ultra-linear channel has the advantage of lowering noise and channel crosstalk while at the same time increasing linearity, dynamic range, and resolution beyond what any single DAC technology can achieve. One listen to this amazing new DAC and you'll know why it easily outperforms single DAC designs.

Octo DAC, Diamond performance

The Stellar Gold DAC is an extraordinary feat of engineering. By combining the outputs of four high-performance D to A converters for each channel, the StellarGold DAC achieves extraordinarily low noise and distortion that rivals any DAC at any price. Combine its state-of-the-art performance with its fully discrete, wicked fast, class A gain stage and you find StellarGold to represent one of the best sounding components in your system. Come learn more about this extraordinary DAC.

Design

The new StellarGold DAC, with its advanced parallel DAC architecture, takes advantage of performance standards unavailable to single DAC designs. By using multiple DACs in parallel, individual non-linearities of each DAC tend to average out. This is because the probability of all DACs having the exact same non-linearity error at the same digital input value is nearly zero. The results are nothing short of breathtaking. One listen to this DAC, and you'll know it's in an entirely different category from others at anywhere near its price range.

Application

PS Audio's StellarGold DAC can become the centerpiece of a high-resolution 2-channel audio system. Using StellarGold's balanced or single-ended outputs into our matching StellarGold preamplifier or, using its built-in lossless volume control, the StellarGold DAC can become the heart of a true state-of-the-art high-performance audio system at an affordable price.

Technology

Parallel DAC Technology

In high-performance audio DACs, employing four parallel DACs per channel offers a number of sonic benefits. First, it reduces noise through averaging, resulting in an impressive signal-to-noise ratio exceeding 127dB below the DAC's maximum output of 4 volts (balanced). When noise is lowered, and the individual non-linearities of each of the 4 DACs are averaged together, the results are an increase in the effective dynamic range (loudest to softest sounds) and an audible improvement in linearity and distortion. The combined resolution effectively surpasses that of any single DAC of similar design on the market, creating an extraordinary audio experience that only a few people have yet to experience. We can't wait for you to hear StellarGold in your system.

Perfectionist Build Quality

The StellarGold DAC was designed by Darren Myers whose mission was to discover how far it might be possible to extend the already extraordinary capabilities of the latest technologies of the top-of-the-line ESS DAC platforms. To do this would require the use of multiple DACS, an all new direct-coupled balanced hybrid output stage featuring a slew rate fast enough to do justice to the circuit's capabilities, and then power the entire circuit with multiple stage linear regulators. A tall challenge given StellarGold's affordable pricing. One look inside at this beautifully hand-crafted device and you'll see how the PS Engineering team honored Darren's original vision using only the highest quality parts and the lowest noise designs. The StellarGoild is truly a work of art that deserves your attention.

State-of-the-art Performance

For the vast majority of audiophiles, the DAC is the cornerstone of their system. Streaming with a network AirLens, a PerfectWave SACD transport, connecting to your computer via USB, or playing music through any digital source is the mainstay of getting music into your home. The quality of that music is directly impacted by the device that converts those digital bits into analog audio we can use to power our speakers. That is the job of the DAC. And DACs are sensitive and highly sophisticated electronic circuits that are affected by any number of issues, including jitter, noise, distortion, resolution, and quantization errors, to mention just a few. When it comes time to find the perfect DAC for your system, it makes sense to turn to a company like PS Audio which places sonic performance and the joy of musicality above all else. If you truly want the next big step in your high-end audio system, consider StellarGold for your your digital playback. We don't think you can get close at anywhere near its price.

Features

  • Four parallel DACs per channel

  • Designed around ESS 9038 Pro technology

  • Dead quiet signal to noise ratio of >127dB referenced to 4V RMS

  • SINAD >112dB referenced to 4V RMS

  • PCM to 768kHz

  • DSD to 256 (11.2mHz)

  • Exceptional imaging and soundstage

  • Discrete hybrid output stage

  • Fully balanced design

  • Multiple low impedance power supplies

  • Low jitter clocking

  • I2S, USB, AES/EBU, coaxial inputs

  • High slew rate, low feedback, class A output stage

Reviews

At the midpoint of [“The Court” by Peter Gabriel], there’s an acoustic piano and, despite hearing this track on upwards of five different DACs, the PS Audio StellarGold DAC delivered one of the most musical, open and airy presentations of that piano recording. There was really good imaging, but even more impressive was the overall depth of the soundstage with the PS Audio StellarGold DAC in the loop. Make no mistake, this is a high-end DAC, and delivers the goods for the money.... Read More

Jerry Del Colliano, Future Audiophile

It brought out sounds and nuances and different instruments that I hadn’t heard before…PS Audio did it right. The DAC’s incredible. It sounds great... Read More

The Absolute Sound: Adrian Alexander Reports

Here the StellarGold gets to show off wide dynamics; there was deep, clean bass next to a startlingly crisp portrayal of Smith's at times forcefully played instrument. The depth of the soundstage impressed, but not as much as the transient attack or the listenability of even the most shrilling, violent blasts of brass... Read More

Hi-Fi News

Awards

Specifications - StellarGold DAC

Physical:

Unit Weight

22.5 lbs [10.2 kg]

Unit Dimensions

17"W x 3"H x 12" D
[43.18 cm x 7.62 cm x 30.48 cm]

Shipping Weight

26 lbs [11.8 kg]

Shipping Dimensions

22"W x 8"H x 17"D
[55.88 cm x 20.32 cm x 43.18 cm]

Color Options

Black
Silver

Power Requirements:

Input Power

Model specific 100VAC, 120VAC, or 230VAC 50 or 60Hz

Power Consumption

30W

Digital Audio Inputs

I2S (2), Coax (2), Optical, USB

Sample Rates

Optical (TOSLink): PCM 16 and 24 bits at 44.1kHz, 48kHz, 88.2kHz and 96kHz
S/PDIF (Coax): PCM 16 and 24 bits at 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz and 192kHz; DoP64
I2S: PCM 16 and 24 bits at 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, 352.8kHz, 705.6kHz, and 768kHz; DoP64, DoP128, DoP256, DSD64, DSD128, and DSD256
USB: PCM 16 and 24 bits at 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, 352.8kHz, and 384kHz; DoP64, DoP128, DSD64, and DSD128

Analog Audio Output

Output Stage

Discrete fully balanced JFET BJT hybrid

Connector

RCA single ended, XLR balanced

Output Level High, Maximum

4 VRMS Balanced
2 VRMS Single Ended

Output Impedance

100‌Ω / 200Ω

Frequency Response

20Hz-20kHz, +/- 0.1dB; 10Hz-70kHz, -1dB

Max Output

4V RMS Balanced, 2V RMS single-ended

THD+N @ 1KHz (full scale)

<0.002% at full output

IMD

<0.002%, CCIF, at full output

SNR

>127dB, referenced to 4V RMS

Data Handling

Format

PCM or DSD

Sample Rate (PCM)

44.1kHz, 48.0kHz, 88.2kHz, 96.0kHz, 176.4kHz, 192kHz, 352.8kHz, 384kHz, 705.6kHz, 768kHz

Data Rate (DSD)

Up to DSD256 (11.2MHz) via DoP and Native DSD1024

Digital Volume Control

Yes

Analog Conversion Method

ES9038PRO DAC

I2S Digital Input:

Connector

HDMI

Format

PCM or DSD. DoP on all inputs as well as native DSD on 12S inputs

USB Digital Input

Connector

USB "B" Type

Format

PCM, DoP v1.1 (DSD over PCM), or Native DSD

Transfer Mode

Asynchronous
